Duo blended cleaner B380L

B380L intensive opener for fiber preparation

Technology for gentle yet intensive opening and cleaning

We have designed the duo cleaner B380L to open and clean raw material efficiently while maintaining fiber integrity.
Its progressive opening and carding action reduce fiber stress without compromising cleaning performance, ensuring high production levels with superior results.

Request info

Machine Features

Production capacity: up to 1,000 kg/h

Two independent beaters with adjustable speeds

Flexible configuration with multiple beater options

Efficient dedusting and blending with 3 m² blending chambers

Easy maintenance & high accessibility

Excellent cleaning & waste reduction

The quality and quantity of waste can be easily adjusted via the deflector blades. At the same time, the progressive opening and carding action improves the selection of the fibers, minimizing material loss.

High flexibility & cost saving

Customers can choose from various beater types (pinned, needle, or sawtooth) to suit different fiber processes. The B380L’s accessible design allows quick beater replacement and easy adjustments, making it ideal for processing multiple materials while maintaining top performance. Its adaptability reduces the need for multiple machines in a blow room, lowering spare part costs and providing a significant economic advantage.

Technical specifications

Processed material	Cotton, man-made fibers and blends Production up to 1,000 kg/h depending on the processed material
Frame width	1,600 mm
Opening roll	400 mm dia.
Speed range	600 - 1,100 rpm
Net weight	4,340 kg
