Duocleaner B390L

B390L double-beater opener for fiber preparation

Excellent cleaning at twice the production rate

We help achieve high quality standards through the efficiency of the B390L cleaner.
Its innovative working concept splits the material into two separate flows, which are processed independently by the two halves of the beaters. Each flow rotates four times around the first semi-beater and another four times around the second, maximizing cleaning efficiency.

Request info

Machine features

Production up to 1,600 kg/h, depending on fiber type

Beaters with different rotating speeds and tip densities, with a faster and more populated second beater

Independent speed adjustment for each beater

Adjustable grids with a total surface area of 2.24 m²

Working width of 1,600 mm per beater for enhanced efficiency

Low fiber stress

Effective cleaning requires proper opening: the Superblender provides mini tufts, while the Duocleaner removes trash particles, fiber fragments, and dust. Thanks to its nip-free design, it ensures low fiber stress and prevents neps formation.

Efficient dedusting system

The waste collected by the four grids is transferred through two bucket wheel locks into a continuous centralized suction system. Additionally, when combined with the B450L, the system effectively dedusts all flocks coming from the bale plucker through its powerful suction mechanism.

Technical specifications

Processed raw material	Cotton, cotton waste, blends up to 65 mm length Production up to 1,600 kg/h depending on the processed raw material
Working width	1,600 + 1,600 mm
Cleaning rolls	700 mm dia.
Speed range	Cleaning roll in 400 - 600 rpm Cleaning roll out 600 - 900 rpm
Net weight	B390L 3,400 kg B450L 1,000 kg
