Superblender B12

B12 automatic bale plucker for fiber blending

Fine raw material plucking

The superblender B12 allows to obtain very small flocks thanks to its two beaters, and two movable conveying rollers that control the material during plucking.
The detacher's free and upright movement, combined with the conveying rollers, allows for smooth and continuous plucking all the way down to the floor.

Request info

Machine features

Production capacity: up to 1600 kg/h, depending on the type of fiber

Two beaters with 254 tips each, ensuring very small flocks

Settable for two blends

Automatic production adjustment

The vertically movable grid with linear transducers controls tips penetration inside the bales, adjusting throughput based on bale height and material levels inside the mixer.

Optimized suction system

The superblender B12 features a downstream cage condenser suction system that eliminates helicoidal airflows inside transportation tubes. This prevents fiber entanglement and neps formation, ensuring a cleaner and more uniform material flow.

Technical specifications

Processed raw material	Cotton, man-made fibers up to 65 mm (2 1/2”)
One assortment	B12 - 1,700 mm up to 1,100 kg/h B12 - 2,250 mm up to 1,600 kg/h Production depending on the processed fibers
One assortment	B12 - 1,700 mm up to 800 kg/h B12 - 2,250 mm up to 1,100 kg/h Production depending on the processed fibers
Space available for bales	ML= E - 5,735 mm
No. of bales each side for one assortment (according to bales dimensions):	wide carriage (ML/B) x 1.5 or (ML/L) x 3 small carriage (ML/B) or (ML/L) x 2 ML= space available for bales B= bale width L= bale lenght
Duct length	E 11.13 - 46.13 m in steps of 2.5 m
Net weight	B12 - 1,700 mm 3,500 kg B12 - 2,250 mm 3,700 kg Approx. 90 kg/m (for variable longitudinal parts)
