Ring frame MDS2
Advanced technology for maximum flexibility and efficiency
Designed for modern textile production, it combines high spindle capacity, full electronic control, and cutting-edge mechanical solutions to maximize productivity, minimize maintenance, and offer flexibility in yarn production. Whether you're targeting large-scale operations or highly specialized yarns, the MDS2 adapts to your needs with superior efficiency and automation.
Machine features
Fully electronic machine up to 2.400 spindles
Independent drives for spindles, ring rail and drafting system to reduce mechanical transmission, friction and vibrations
Optimized suction system to minimize energy consumption (up to 50% energy saving on suction)
All technological parameters (count, S or Z twist, speed, etc.) setting on the touch screen display
Easy, fast and efficient maintenance and cleaning
Possibility to pre-arrange the machine for the production of core spun, duocore and double roving yarns
Tangential belt multi motor drive
The tangential belt multi motor drive offers significant advantages, requiring less maintenance and ensuring a cleaner machine environment, as there is no need to replace tapes or adjust pulleys and shafts. This solution improves belt adherence on the spindle wharves, maintaining speed variation among spindles below 1%.
Smart automation with high-speed doffing
TheMDS2 features an advanced automatic doffing system that completes a full cycle in under two minutes. Thanks to its dedicated parking rail design, it allows for larger cops and fewer doffing interruptions. The entire process is fully automated and precisely controlled to minimize ends down and maximize productivity.
Technical specifications
| Material | Carded and combed cotton man-made fibers and blends, up to 60 mm |
| Yarn count range | Ne 4 - Ne 350 / Nm 6 - Nm 678 / Tex 150 - Tex 1,68 |
| Yarn twist range | Tw/" 4 - 56 / T/M 160 - 2,210 |
| Direction of twist | Z-S twist |
| Draft | 7.5 - 80 |
| Number of spindles | up to 2,400 |
| Spindles gauge | 70 mm - 75 mm |
| Ring diameter | 36 - 54 mm |
| Tubes leng | 180 - 260 mm |
| Spindles speed | max 25,000 rpm (mechanical) |
Discover ring frame MDS2
Download the brochure to discover all the advantages and features of this machine.
